  • Compatible spacing between pillars: 354.5 cm
  • Width: 349.5 cm and Height: 145.2 cm
  • Ideal for a unique and streamlined entryway
  • Accessories included

CASA8

Swing gate 3.5m CERVINA RUIVO H.140cm gray aluminum

KIT-000750

£1049

-8% with code CASA8 until 15/04 🏷️

code:

* Priority booking
At your place from 18/05!
:
:
:
  • Compatible spacing between pillars: 354.5 cm
  • Width: 349.5 cm and Height: 145.2 cm
  • Ideal for a unique and streamlined entryway
  • Accessories included
Secure payment

Secure payment

Delivery within 5 days

Delivery within 5 days

Free shipping

Free shipping

Swing gate 3.5m CERVINA RUIVO H.140cm gray aluminum

£1049

* Priority booking

Discount Pack

Save money!  Discover the packs bundled with this product

Description

Bring modernity and originality to your entrance with the CERVINA RUIVO swing gate.

Combining the solid, contemporary structure of the CERVINA with the openwork geometric patterns of the RUIVO range, this gate creates a captivating play of light when the sun illuminates your exterior. Its graphic and modern design adds depth and lightness to your facade, while preserving your privacy on the sides.

Swing Gate: A timeless design for wide and easy opening

The double-leaf gate stands out for its ease of use and timeless design. Its two leaves offer a wide opening, facilitating vehicle access. Robust and durable, it is designed to withstand the elements and requires minimal maintenance. The swing gate is the perfect option for those seeking both security and aesthetics. And if you would like a motorized gate, you can automate its operation with a swing gate motor.

This swing gate has a wind resistance of 55 km/h.

Material: Aluminum
Color: Anthracite Gray RAL 7016
Dimensions: Width 349.5 cm - Height 145.2 cm
Total width required with clearance: 354.5 cm
Minimum post height: 160 cm

This kit contains:

- 14 powder-coated slats (15.5cm wide)
- 2 reinforced slats for motorization
- 2 decorative aluminum plates
- 2 upper hinges mounted on ball bearings
- 2 lower hinges
- 1 automatic center stop
- 2 receiving stops
- 1 cylinder lock
- 1 handle (Black)
- 5 keys
- Finishing covers
- Screws

About the Material

Aluminum stands out for its lightness, robustness, and corrosion resistance. This material does not rust and retains its appearance over time, even in harsh weather. Easy to maintain, simple regular cleaning is all it takes to preserve its original shine. Durable and aesthetically pleasing, aluminum is ideal for your outdoor spaces, offering a modern and high-performance solution. By choosing aluminum, you combine practicality, longevity, and elegance every day.

The minimum height of the pillars for this swing gate is 160 cm.

How to maintain your aluminum structure?

Aluminum requires little maintenance, but regular cleaning prolongs its lifespan. Once or twice a year, simply use warm soapy water with a soft cloth, then rinse and dry thoroughly. Avoid abrasive products and high-pressure cleaning, which could damage the lacquer.

Need help choosing your swing gate?

Contact our customer service department via our online form.

For this product

Clear instructions

Quick and easy assembly

Find all the necessary information about this product in the Technical specifications

Download the instructions

Technical diagram

Technical data

  • Frame material

    Aluminium

  • Central stop

    Yes

  • Top cover cap

    Yes

  • Opening direction

    Opening to the right, swinging towards the house

  • Compatible pillar spacing

    101-104 cm

  • Main material

    Aluminum

  • Colour

    Charcoal grey

  • RAL

    7016

  • Type of lock

    Keys (5)

  • Operating clearance

    15 mm

  • Pivoting system

    Ball bearing

  • Blade section

    155*15 mm

  • Amounts Section

    78*47mm mm

  • Rod assembly

    Self-drilling screws

  • Sleeper Section

    70*30 mm

  • Stud/rail assembly

    Self-drilling screws

  • Locking system

    Barrel lock

  • Assembly time

    4 h

  • Height

    153 cm

  • Width

    98.2 cm

  • Width between pillars

    102.5 cm

  • Thickness of the blades

    1.2 mm

  • End stop

    2

  • Wind resistance

    55 km/h

  • Supplied accessories

    Yes

  • Sleeper thickness

    1.3 mm

  • Number of upper hinges

    1

  • Stud thickness

    1.5 mm

  • Minimum pillar height

    175 cm

  • Number of lower hinges

    1

  • Finishing

    Powder coating

  • Type of filling

    half openworked

  • Opening system

    Swing gate

  • Handle material

    Aluminum

  • Handle colour

    Black

  • Assembly instructions

    Yes

  • Recommended number of persons for assembly

    2

  • Warranty

    2 an(s)

  • Eligibility Extended warranty 5 years

    No

  • Eligibility Extension of warranty 10 years

    No

  • Available in sliding

    No

  • Compatible engines

    Yes
